Chicago Pneumatic CP7755 Airflex Mini Impact Wrench 1/2" 1300Nm
Features:
Complete power control
High accessibility / maneuverability
Ergonomic
Lightweight
High durability
High comfort
Improved safety
The best and the most adjustable power control for pneumatic tools
5, 10, 15, 20, 25, 30, 35, 40, 45, 50 and 100% of maximum torque
Air Flex Mini integrated (Patented)
Composite motor housing (4.25 lbs / 1.93 kg)
Twin hammer mechanism
Bumpers all over the tool
Bi-material and bi-color handle and trigger
Friction ring socket retainer
*Final torque must be applied manually using a calibrated torque wrench (please refer to the operator’s manual)
Specifications:
Square drive: 12.7mm (1/2")
Socket retainer: Friction ring
Clutch type: Twin hammer
Actual air consumption: 108 l/min (3.9 cfm)
Free speed air consumption: 156 l/mn (5.6 cfm)
Blows per minute: 1,200
Free speed: 7,700 rpm
Maximum Torque (fwd): 1080 Nm (796 ft.lbs)
Working Torque Range (fwd): 80 - 575 Nm (59 - 425 ft.lbs)
Maximum Torque (reverse): 1300 Nm (960 ft.lbs)
Height: 205mm (8.1")
Length: 169mm (6.65")
Width: 76 mm (3 ")
Side to center: 38mm
Net weight: 1.93kg
Power/weight ratio: 673 Nm/kg (225 ft.lb/lb)
Min. hose size: 10 mm 3/8"
Air inlet thread size: 1/4"
Sound Power: 105 db(A)
Sound pressure: 94 db(A)
Sound uncertainty: 3 db(A)
Vibration: 8.5 m/s²
Vibration ISO: ISO-28927-2
Vibration uncertainty (K): 3.4 m/s²
European Directives: 2006/42/EC (17/05/2006)
European Sound Standard: EN ISO 15744
European Standards: EN ISO 11148-6:2013
